Milled Finished Electric Vehicle Lithium Ion Battery Cooling Ribbon
Liquid cooling technology reduces the battery temperature by taking away the heat generated by the battery through liquid convection heat transfer. The high heat transfer coefficient, high heat capacity and fast cooling speed of the liquid medium are effective in reducing the maximum temperature and improving the consistency of the temperature field of the battery pack, while the size of the thermal management system is relatively small.
Detials:
| Cooling plate | Lithium Ion Battery Cooling Ribbon |
| Thickness | Customized (We will suggest according to your cells) |
| Width/Length | Customized ((We will suggest according to your module) |
| Battery | Cylindrical cells 18650, 21700, 3270, 4680, 4695, 46165, punch pack and Prismatic cell, etc. |
| Surface treatment | Insulation coating, with thermal interface material |
| Applications |
|
Our Advantages:
1. Tooling development — we do it in house, so we can make initial testing prompt and accurate.
2. Making all kinds of heat exchangers — we can do customized shape, to make the parts fit into different packs.
3. Assistance in parts design — we have experienced engineer team, they can provide professional suggestions regarding feasibility of carrying out new designs.
4. One station service — we can do heat exchangers, as well as its related insulation, silicon pad and external pipeline. So client can get integrated solution.
Water-cooled Tube for ESS, liquid cooling tube, snake tube for ESS, cylindrical tube, aluminum ribbon, snake radiator, serpentine cooled tube, battery heat exchanger, liquid cooling plate for electric 3 wheeler.
Water cooling system structure: medium, liquid cooling plate/tube, water cooled head (manifold), pump, pipeline...
FAQ
Q: What kind of battery cold plate can you provide?
A:
1) Stamped cooling plate for prismatic cells / battery pack.
2) Serpentine tube for cylindrical cells, such as 21700, 18650, 3270, 4680 big cell.
3) Extruded tube with manifold for soft battery pack.
4) Roll bond cooling plate for heating / cooling.
Q: What method of processing technology?
A: We have brazing line, stamping line, extrusion line, and roll boned process line. Also CNC centre is available.
Q: If we don't have design, can you assist in design?
A: Yes, we can! We have a strong and experienced design team. Flow path design, thermal simulation, mechanical simulation and design optimation are support. Kindly share with us your detail project, service8@trumony.com, we'd love to do DFM for you.
Q: How fast you can make prototype?
A: About 3~5wks. The precise lead time will depends on your design and producing process.
