Brazing Aluminum Clading Coil Hot Rolling Coated Aluminum Strip for Heat Exchange

For brazing material, we can supply aluminum fin, tubes (high-frequency welded tube, micro channel extrusion tube) and plates.

We can provide the following specifications:

Core material: 3003+1%Zn/3003+1.5%Zn/3003+Zr/3003+0.5%Cu/3005 etc.

Cladding material: 4343/4343+1%Zn/4045/4045+1%Zn/4004/7072/5005 etc.

Cladding rate: 4~18% (each side)

Temper: HO/H14/H16/H18/H24

Size: Fin: 0.07/0.08 * (16-28)mm

Tube: (0.27-0.32)*(35-75)mm

Plate: (0.6-1.5)*(1070/1000/659)*(500-2500)mm

Applications:

1) Condensers
2) Evaporators
3) Oil coolers
4) Heater cores

5) Refrigerator

6) Air conditioner

5)Electrical Vehicle battery cooling, such as serpentine tube/snake tube
